Configuration CP384
4.3.3 Channel Connection
The following diagrams illustrate the external connection of the CP384 to the application.
Figure 4-5: Digital Output Connectionr
Figure 4-6: Digital Output Circuit
CP384
CON2
+
External
VCC
External GND
Supply Voltage
NC
C
NO
NC
C
NO
V
ExtVCC
Channel 0
Channel 7
ExtGND
L
O
A
D
L
O
A
D
CP384
CON2
External VCC
EXTGND
External GND
+
External
VCC
V
Supply Voltage
Ch 0
NC NO
relay
coil
relay
driver
L
O
A
D
NO
NC
C
C
