Parts Inventory
The table below lists all parts in the kit. If you have trouble identifying any of these items, consult the
K2 Owner's manual, which has photographs of similar parts.
Ref. Description Qty.
C16 Capacitor, 39 pF, 5%, disc 1
C4 Capacitor, 100 pF, 5%, disc ("101") 1
C3 Capacitor, 820 pF, 5%, disc or monolithic ("821") 1
C9, C11, C13 Capacitor, .001 µF disc or monolithic ("102") 3
C6 Capacitor, 1500 pF, 5%, disc or monolithic ("152") 1
C7 Capacitor, 1800 pF, 5%, disc or monolithic ("182") 1
C12 Capacitor, .0068 µF disc or monolithic ("682") 1
C8, C14, C17 Capacitor, .01 µF disc or monolithic ("103") 3
C10 Capacitor, 0.1 µF disc or monolithic ("104") 1
C15 Capacitor, electrolytic, 22 µF 1
D2, D3 Diode, 1N34A (alternates: 1N191, 1N5711) 2
L1, L2 Toroidal inductor, 1.2 µH, 16 turns #26 on T37-2 core (red) 2
L3 Toroidal inductor, 40 µH, 15 turns #26 on FT37-43 core (gray) 1
P1 Conn., 8-pin male, 0.1" spcg., gold, Samtec TSW-108-07-G-S 1
Q1, Q2, Q4, Q7 Transistor, PNP, 2N3906 4
Q3, Q5 Transistor, NPN, 2N2222A 2
Q6 Transistor, MOSFET, 2N7000 1
R8 Resistor, 120 ohms, 1/4 W, 5% (brown-red-brown) 1
R4, R5, R6 Resistor, 220 ohms, 1/4 W, 5% (red-red-brown) 3
R9 Resistor, 300 ohms, 1/4 W, 5% (orange-black-brown) 1
R3 Resistor, 1.8 K, 1/4 W, 5% (brown-gray-red) 1
R7, RF-R88 Resistor, 2.7 K, 1/4 W, 5% (red-violet-red) 2
R10 Resistor, 1 megohm, 1/4 W, 5% (brown-black-green) 1
R1 Resistor, 100 K, 1/4 W, 5% (brown-black-yellow) 1
RP1,RP2 Resistor network, 3.9 K, 4 resistors (isolated), 8 pins 2
U1 IC, RF amplifier, MC1350P 1
U2 IC, voltage regulator, 78L06 1
U3 IC, Microcontroller, 12C509A (alternate: 12C508A) 1
(parts list continues on next page)
