EFCO 8800 Series Assembly Instructions Vol.4 - Manual (Page 7)

EFCO 2009 Page 7
Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 4
Section 11 - Outside 90° Corner SSG Unit Glazing : B. Setting and Caulking Glazing
Figure 3
5. Remove the temporary glazing retainers.
6. Apply structural silicone sealant into the void between the glass and mullion per the sealant manufacturer’s application instructions. Frames should not be
moved until the sealant has cured and per the sealant manufacturer’s recommendations.
7. Refer to Volume 2, page 9 and 10 of the S-8000 Unitized Curtain Wall Assembly Instructions for glazing instructions, details and notes.
Note:
Only silicone sealants which
have been developed and tested
specifically for structural
glazing applications should be
used for glazing purposes.
Apply Structural
silicone
Pack sealant
into joint
HEAD
SILL
