U S E R G U I D E

Flow Meter Testing

Version 1

Flow Meter User Guide

5

F

LOW

M

ETER

T

EST

P

OINTS

The following table describes the flow meter readings for a new, rebuilt, or dirty
air pump in liters/minute. Perform all of the tests outlined in this manual and fill
out your results in the data tables on page 16. When you have completed all of the
tests, compare your results with the following table. If the flow meter reading is
equal to or lower than the dirty air pump reading, follow the steps outlined in the
action required column of the table. Pump head rebuild kits (P/N 79190003) are
available from Dynojet. Refer to the Air Fuel Ratio Module Installation and User
Guide (P/N 98295110) for rebuild instructions.
Note: If at any test point, the ball in the flow meter bounces erratically
(+/- 20L/min.) the pump heads need to be rebuilt. Pump head rebuild kits
(P/N 79190003) are available from Dynojet. Refer to the Air Fuel Ratio Module
Installation Guide (P/N 98295110) for rebuild instructions.

test point

new or rebuilt
pump

dirty pump

action required

test point one

35

25 or less

rebuild pump heads

test point two

28

25 or less

clean or replace filter

test point two—filter

assembly

less than 2

greater than 2

clean and tighten filter

housing

test point three

28

25 or less

rebuild pump heads

test point three—sensor

block assembly

less than 2

greater than 2

clean and tighten sensor

test point four

30

25 or less

rebuild pump heads

test point five

30

25 or less

rebuild pump heads
