U S E R G U I D E
Flow Meter Testing
Version 1 Flow Meter User Guide
3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FLOW METER TESTING
This section describes the five test point procedures using the flow meter to test the
air pump.
• Test Point One—Overall System Flow, page 7
• Test Point Two—Filter Flow, page 8
• Test Point Three—Pump Inlet Port, Sensor Side, page 10
• Test Point Four—Left Outflow, page 12
• Test Point Five—Right Outflow, page 13
Figure 1: Flow Meter
plug
liters/minute
top port
bottom port
