2
Unpacking & Pre-installation
Carefully remove the LIT3 Mounting Kit from the shipping carton, taking care not to scratch the lenses of the LED Lightheads (if so
equipped). Examine the unit for transit damage, etc. Report any damage to the carrier and keep the shipping carton.
Standard lightbars are built to operate on 12 volt D.C. negative ground (earth) vehicles. If you have an electrical system other than 12
volt D.C. negative ground (earth), and have not ordered a specially wired lightbar, contact the factory for instructions.
If the units you have are the lighted version, test the unit before installation. To test, touch the black wire to the ground (earth) and the red
wire to +12 volts D.C.,
Installation & Mounting
Mounting Hardware -
All mounting hardware is packed in a small bag inside the main carton. The main components in the kit are (2) Molded Plastic Mounting
Feet, (2) Stainless Steel Mounting Brackets, (2) Gutter Hooks, and other required hardware. These are all discussed in detail later
Utilizing non-factory supplied screws and/or mounting brackets and/or the improper
number of screws may result in loss of warranty coverage on the equipment.
Do not attempt to attach the mounting feet in any manner
other than described in the following pages. Do not drill
holes through the mounting feet and attach with fasteners
to the vehicle frame. This will void the warranty.
WARNING!
!
The use of this or any warning device does not ensure that all drivers can or will observe or react to an emer-
gency warning signal. Never take the right-of-way for granted. It is your responsibility to be sure you can proceed
safely before entering an intersection, driving against traffic, responding at a high rate of speed, or walking on or
around traffic lanes.
The effectiveness of this warning device is highly dependent upon correct mounting and wiring. Read and follow
the manufacturer’s instructions before installing or using this device. The vehicle operator should insure daily that
all features of the device operate correctly. In use, the vehicle operator should insure the projection of the
warning signal is not blocked by vehicle components (i.e. open trunks or compartment doors), people, vehicles, or
other obstructions.
This equipment is intended for use by authorized personnel only. It is the user’s responsibility to understand and
obey all laws regarding emergency warning devices. The user should check all applicable city, state and federal
laws and regulations.
Code 3, Inc., assumes no liability for any loss resulting from the use of this warning device.
Proper installation is vital to the performance of this warning device and the safe operation of the emergency
vehicle. It is important to recognize that the operator of the emergency vehicle is under psychological and
physiological stress caused by the emergency situation. The warning device should be installed in such a manner
as to: A) Not reduce the output performance of the system, B) Place the controls within convenient reach of the
operator so that he can operate the system without losing eye contact with the roadway.
Emergency warning devices often require high electrical voltages and/or currents. Properly protect and use
caution around live electrical connections. Grounding or shorting of electrical connections can cause high current
arcing, which can cause personal injury and/or severe vehicle damage, including fire.
PROPER INSTALLATION COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF EMER-
GENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF EMERGENCY PERSONNEL
AND THE PUBLIC.
WARNING!
!
Introduction
The new LIT3 Mounting Kit is a system that provides an attractive and convenient means to attach many of the Code 3 Lightbar Products
to Emergency Vehicles.
The Lighted Version can be ordered with 55 watt takedown/alley lights and/or 3 LED optix lightheads in Red, White, Blue or Amber.
