Code 3 LIT3 Mounting Kit - Manual (Page 11)

11
Troubleshooting
LED module housings may become hot with extended
use. Allow modules to cool completely before attempting
to remove.
WARNING!
!
TROUBLESHOOTING
Problem Probable Cause Remedy
Lighthead does not
activate
a. No Power to unit
b. Power input wire
reversed
c. Damaged or shorted
cabling
d. Defective Lighthead
e. Control wire permanently
grounded or shorted to
GND
a. Check wiring for loose
connection
b. Reverse Power wires
c. Check cables for damage
d. Replace lighthead module
e. Avoid permanent grounding
of control wire
Lighthead is constantly
ON
a. Control wire permanently
grounded or shorted to GND
a. Avoid permanent
grounding of control
wire
Maintenance:
The Exterior LED Modules are completely sealed units designed to be trouble and maintenance free. Refer to the guide below for help
with troubleshooting. Should the unit be diagnosed as malfunctioning, remove unit and replace with a new module.
This Product contains high intensity LED devices. To prevent eye damage,
DO NOT stare into light beam at close range.
! WARNING!
Features and Specifications:
Operating Voltage: 10-16Vdc Reverse Polarity Protection.
Flashing Current Draw:
Red/Amber: - .25A Avg.
Blue/White: - .4A Avg.
Steady Burn Current Draw: Red/Amber: - .5A Avg.
Blue/White: - .8A Avg.
Available colors - Red, Amber, White or Blue
Available configurations - Directional, wide, and hybrid optics (combination of directional and wide individual optics).
Setting Flash Patterns
To change the flash pattern, hold the White wire to Ground for at least 1 second, and less than 3 seconds, and then release. While holding
the White wire to Ground the head will stop flashing until released.
Note: In some instances the white wire may be trimmed flush to the potting material. Use a grounded sharp metal rod, such as a scratch awl
with a wire attached to ground, to touch the wire stub and connect to ground.
The tables below show the available flash options and their selection order for each mode. Heads will come from the factory preset to the
default Cycleflash pattern.
Flash Pattern Description
1 Cycleflash (Factory default)
2 Quadflash
3 Doubleflash
4 Singleflash
5 Steady Burn
Note: All flash patterns are 70 fpm.
