Code 3 LIT3 Mounting Kit - Manual (Page 12)

12
Reference Number Part Description Part Number
1 Mounting Foot no lights T09719
2 Mounting Foot with lights T09718
3 Slide Shelf Left T09720
4 Slide Shelf Right T09723
5 Frame Bracket and Cage Nut - no lights T09717
6 Frame Bracket and Cage Nut - with lights T09850
7 Socket Head Cap Screw SS (5/16"-18 x 3") T09724
8 Phillips Pan Head Screw SS (5/16"-18 x 3") T13934
9 55w H3 Halogen Replacement Lamp T09739
10 55w Halogen Lighthead w/Lamp T09727
11 3Up Optix LED lighthead Contact factory for part number
12 Rubber Spacer - for rubber foot T09722
13 Rubber Foot - for automobile roof T09734
14 Rubber Foot - for flat surface/perm mount T09863
15 Adapter Bracket - for flat surface/perm mount T09864
16 Vehicle Mounting Plate (gutter hook) Contact factory with make and model
Parts List
