BoonDocker ARCTIC CAT: 2012-14 ProClimb M8 Intercooled User Manual
Page 16
BoonDocker tollfree: 877-522-7805 local: 208-542-4411 fax: 208-524-7381 www.boondockers.com 16
sel
Stock Connectors
Arrows represent
Temp Sensor
Chassis Ground
CB Capture Button
Fuel Booster
ADA Harness
Injector Harness
TPS
Aux Injector
Aux Injector
Stock Injectors
Stock Fuel Pump
Stock Accessory Plug
Boost Transducer
WIRING DIAGRAM - Control Box with Fuel Booster Board
