Connecting a tv – AVer SPB350+ User Manual
Page 7
ENGLISH
5
C
C
o
o
n
n
n
n
e
e
c
c
t
t
i
i
n
n
g
g
a
a
M
M
o
o
n
n
i
i
t
t
o
o
r
r
o
o
r
r
L
L
C
C
D
D
/
/
D
D
L
L
P
P
P
P
r
r
o
o
j
j
e
e
c
c
t
t
o
o
r
r
w
w
i
i
t
t
h
h
D
D
V
V
I
I
i
i
n
n
t
t
e
e
r
r
f
f
a
a
c
c
e
e
Locate the DVI input port of the display device and connect it to DVI-I OUT port of SPB350+. If you are not sure,
please refer to the user manual of the device.
Make sure the Video Output switch is set to RGB.
SD CARD
USB
DVI-I OUT
CVBS OUT
S-VIDEO OUT
LCD/DLP Projector
with DVI interface
LCD Monitor
with DVI interface
DVI cable
(not supplied)
C
C
o
o
n
n
n
n
e
e
c
c
t
t
i
i
n
n
g
g
a
a
T
T
V
V
Locate the VIDEO (yellow), S-VIDEO or SCART RGB input port of the TV or Video equipment (i.e., VCR) to record
your presentation on a videotape and connect it to S-VIDEO or CVBS OUT port of SPB350+. If you are not sure,
please refer to the user manual of the TV or Video equipment.
- Make sure the Video Output switch is set to TV.
- For better video quality, we strongly suggest using S-VIDEO connection.
SD CARD
USB
DVI-I OUT
CVBS OUT
S-VIDEO OUT
S-Video cable
S-Video to SCART cable
(not supplied)
S-VIDEO
RCA to SCART cable
(not supplied)
RCA cable
VIDEO
SCART
SCART
INPUT
Projector
TV
VCR
