UG042, August 19, 2014 7
feature is used. NOT Available for HD1000. other devices, connect directly to
observation point for error.
CONFIG_SCRUBBING_ENABLE CFG Input
Enables SCRUB feature for SEU mitigation in the configuration
memory. NOT Available for HD1000.
For the HD1000 tie this pin to GND. For
other devices, connect this pin directly to
the configuration controller.
CONFIG_SCRUB_SINGLE_ERR CFG Output
Indicates the presence of a single error when the SCRUB
feature is used. NOT Available for HD1000.
For the HD1000, leave unconnected. For
other devices, connect directly to
observation point for error.
General Purpose I/O Interface
RCOMP_TERM_B
[00,01,02,10,11,12,20,21,22,
30, 31,32,40,41,42,50,51,52] BWN, BWC,
BWS, BES,
BEC, BEN
Input
Termination resistor input for dynamic drive compensation
for PVT and aging.
Terminate to GND through a changeable /
swappable resistor that will provide the
correct termination. Currently a 200Ω +/-
1% resistor is being used internally.
RCOMP_DRV_B
[00,01,02,10,11,12,20,21,22,
30, 31,32,40,41,42,50,51,52] BWN, BWC,
BWS, BES,
BEC, BEN
Input
Drive resistor input for dynamic drive compensation for PVT
and aging.
Terminate to GND through a changeable /
swappable resistor that will provide the
correct drive strength. Currently a 25Ω +/-
1% resistor is being used internally.
PAD_[WS/WC/WN/ES/EC/EN]_BYTEIO
[12:0]DQ[9:0]
BWN, BWC,
BWS, BES,
BEC, BEN
Input /
Output
A group of 13 byte lanes. Each byte lane has 12 bits; 10 of
these 12 bits are used as data for memory interface
applications. Alternatively, these I/Os could be set for Single
Ended, Differential, LVCMOS, *STL and LVDS modes.
Unused I/Os can be left unconnected.
PAD_[WS/WC/WN/ES/EC/EN]_BYTEIO
[12:0]DQS
BWN, BWC,
BWS, BES,
BEC, BEN
Input /
Output
A group of 13 byte lanes. Each byte lane has 12 bits; the 11th
bit carries a synchronous strobe signal (positive polarity
differential clock) for referencing DQ[9:0] in each of the byte
lanes. Alternatively, these I/Os could be set for Single Ended,
Differential, LVCMOS, *STL and LVDS modes.
Unused I/Os can be left unconnected.
PAD_[WS/WC/WN/ES/EC/EN]_BYTEIO
[12:0]DQSN
BWN, BWC,
BWS, BES,
BEC, BEN
Input /
Output
A group of 13 byte lanes. Each byte lane has 12 bits; the 12th
bit carries a synchronous strobe signal (negative polarity
differential clock) for referencing DQ[9:0] in each of the byte
lanes. Alternatively, these I/Os could be set for Single Ended,
Differential, LVCMOS, *STL and LVDS modes.
Unused I/Os can be left unconnected.
Clock I/O Interface
RCOMP_TERM_CLK_BANK_[NW/SW/S
E/NE] CB0, CB1,
CB2, CB3
Input
Termination resistor input for dynamic drive compensation
for PVT and aging.
Terminate to GND through a changeable /
swappable resistor that will provide the
correct termination. Currently a 200Ω +/-
1% resistor is being used internally.
RCOMP_DRV_CLK_BANK_[NW/SW/SE
/NE] CB0, CB1,
CB2, CB3
Input
Drive resistor input for dynamic drive compensation for PVT
and aging.
Terminate to GND through a changeable /
swappable resistor that will provide the
correct drive strength. Currently a 25Ω +/-
1% resistor is being used internally.
PAD[5:0]_CLK_BANK_[NW/SW/SE/NE]
CB0, CB1,
CB2, CB3
Input /
Output
A group of six clock buffers that can be used either as three
differential I/Os or six single‐ended I/Os. If these I/Os are not
used as clock buffers, they can be used as generic inputs or
outputs.
Unused I/Os can be left unconnected.
