Wire connection, English – Clarion MAX667VD User Manual
Page 70
70
MAX667VD
English
IN
ST
AL
LA
TION
AND
WIR
E
CONNE
CT
ION MA
NUAL
7. WIRE CONNECTION
• Before installing, be sure to disconnect the negative cable of the car battery.
• In the optional devices, the RCA Pin and the Connector cable are separately-sold items.
Note:
iPod
(CCA-670-600)
Yellow
TV tuner input terminal
DVD changer input terminal
Optical output terminal
Radio
antenna jack
Connector cable
CCD terminal
4-Channel Amplifier
Red
Red
White
Right
left
Front audio output
terminal
Right
left
Rear audio output
terminal
Right
left
Non fader
output terminal
Gray
Black
Purple
Red
White
CeNET
terminal
Yellow
Video output terminal
Right
Left
(2-ZONE
output terminal)
Gray
Green
Red
White
Wireless
Headphone
Yellow
White
Red
Video
Audio (left)
Audio (right)
Visual input
terminal
VTR etc.
Black
Red
White
TV
IN
DVD A/C
IN
Rear monitor
(WH100/
WH200)
