Basic Operations
29
MAX667VD
English
Owner
’s ma
nua
l
Monitor image and sound with 2-ZONE ON/OFF
●With 2-ZONE function OFF
●With 2-ZONE function ON
*1: A device connected to the Visual terminal should be set up as described in the section “Switching
CONNECT(connect)”.
*2: No image is displayed on the rear monitor when a non-image mode such as CD changer mode, etc.
is selected.
*3: For safety reasons, this image is not displayed when the vehicle is moving. The picture can be
watched only when the vehicle is stopped and the parking brake is applied.
Front monitor lock ON Front monitor lock OFF
Visual
connection
[OTHER] (*1) Visual
connection
[NAVI] (*1) Visual
connection
[OTHER] (*1) Visual
connection
[NAVI] (*1)
Front monitor
(main unit) Displays image of
device connected
to the Visual
terminal. (*3) Displays image of
device connected
to the Visual
terminal. Displays image of mode selected from
the Source menu.
Rear monitor
(optional) Displays image of mode selected from the Source menu. (*2)
Audio output Sound from mode selected from the Source menu is output from 4ch speaker,
NON-FADER, and AUDIO-OUT.
Front monitor lock ON Front monitor lock OFF
Visual
connection
[OTHER] (*1) Visual
connection
[NAVI] (*1) Visual
connection
[OTHER] (*1) Visual
connection
[NAVI] (*1)
Front monitor
(main unit) Displays image of
device connected
to the Visual
terminal. (*3) Displays image of
device connected
to the Visual
terminal. Displays image of mode selected from
the Source menu in the MAIN zone
mode.
Rear monitor
(optional) Displays image of mode selected from the Source menu in the SUB zone mode.
(*2)
Audio output • Sound from mode selected in the MAIN zone mode is output from 4ch speaker,
NON-FADER and AUDIO-OUT.
• Sound from mode selected in the SUB zone mode is output from SUB-OUT.
