CRAFTSMAN TABLE SAW - MODEL NO. 315.228310
The model number will be found on a plate attached to the cabinet. Always mention the model number in ail correspondence regarding your TABLE
SAW or when ordering repair parts.
PARTS LIST FOR FIGURE G
KEY
PART
NO.
NUMBER
DESCRIPTION
QUAN.
1
979992-001
Base................................................................................................................................
2
** STD523105
* Bolt (5/16-18 X 1/2 in. Hex Hd.)........................................................................................ .......................................3
3
980588-001
* Star Washer (5/16 in.).......................................................................................................
4
979918-001
Handwheel Assembly (Includes Key Nos. 5, 6, and 7).................................................... .......................................2
5
977229-001
Handle..............................................................................................................................
6
977491-001
Screw (M8x 1.25 in.)........................................................................................................
7
977481-001
End Cap ........................................................................................................................
8
980602-001
* Screw (3/16-24 x 1/2 in. Socket Hd.)................................................................................
9
" STD551010
* Washer (#10)....................................................................................................................
10
** STD511005
* Screw (#10)......................................................................................................................
11
980599-001
Cord Clip..........................................................................................................................
12
980320-001
Bevel Scale Label............................................................................................................
13
980325-001
Data Plate........................................................................................................................
'Standard Hardware Item — May Be Purchased Locally
"Available From Div. 98 — Source 980.00
