SMALL PARTS LIST
Check all loose parts from the box with the list on the previous page, the figures below and on the following
page. Small items such as fasteners and end caps are shown in figures 2 b and 2 c. Follow the instructions in
the Assembly section to assemble your new saw.
F.
Hardware for Handwheel......................................2
screw (3/16-24 x 1/2 in.)........................................2
fiat washer (3/16 in.).............................................. 2
□SMI 0
V. Hardware for Mounting Motor, Motor Mounting
Plate, and Belt Guard
Hardware for Mounting Motor...............................1
hex bolt (5/16-18 x 1 in.)........................................4
flat washer (5/16 in.).............................................. 8
lock washer (5/16 in.).......... .'................................4
hex nut (5/16-18)....................................................4
n.
inivmnwwu
LJ
Hardware for Motor Mounting Plate....................... 1
hex bolt (5/16-18
X
5/8 in.)......................................2
n
...............
l.l№WW
LJ
Hardware for Belt Guard........................................ i
hex nut (3/16-24)................................................. 4
flat washer (3/16 in)............................................... 4
© ©
W. Hardware for Table Extensions............................ i
hex bolt (5/16-18x1-1/4 in.)................................... 8
flat washer (5/16 in.)............................................16
hex nut (5/16-18)...................................................8
X, Hardware for Leg Stand, Leveling Feet, and
Mounting Saw Base
Hardware for Leg Stand........................................ i
carriage bolt (5/16-18 x 3/4 in.)...........................24
flat washer (5/16 in.)......................................... 24
hex nut (5/16-18)................................................ 24
dju @ ©
Hardware for Leveling Feet..................................1
leveling foot......................................................... 4
flat washer (5/16 in.)........................................... 8
hex nut (5/16-18).................................................. 8
Hardware for Mounting Saw Base....................... 1
hex bolt (5/16-18
X
1/2 in.).................................... 4
flat washer (5/16 in.)............................................. 8
hex nut (5/16-18).................................................. 4
@ ©
Fig. 2 b
11
