CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220381
The model number will be found on a plate attached to the base. Always mention the model number in aii correspondence regarding your RADIAL
ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE I
-vi
■ vi
3)
>
S
>
I—
Cn
%
Cd
KEY
NO.
PART
NUMBER DESCRIPTION QUAN.
KEY
NO.
PART
NUMBER
1 976366-001 Guard Screw (10-24 Slotted)................... ........... 1 17 977246-001
2 977237-001 Inner Lower Guard................................... ........... 2 18 706382-041
3 976370-002 Shoulder Screw (1/4-20 Button Hd.)... ........... 2 19 977254-001
4 979528-001 Guard Nut (10-24)..................................... ........... 1 20 977240-001
5 641180-003 * Push Nut (1/4 in.)....................................... ........... 1 21 977239-001
6 977244-001 Knife Support........................................... ........... 1 22 641180-004
7 621032-009 Star Washer.............................................. ........... 1 23 976879-002
8 977478-001 Slotted Nut................................................ ........... 1 24 977480-003
9 *• STD541425 * Lock Nut (1/4-20)....................................... ........... 1 25 •* STD533106
10 931744-059 Washer...................................................... ........... 2 26 977225-001
11 977243-001 Anti-Kickback Pawl.................. ............... ........... 4 27 977224-001
12 977253-001 Bushing.................................................... ........... 2 28 977223-001
13 ** STD512510 * Screw (1/4-20 X1 in. Pan Hd.).................. ........... 1 29 977238-001
14 980498-001 Outer Lower Guard Assembly............... ........... 1 30 977230-001
15 976370-001 Shoulder Screw (1/4-20 Button Hd.).. ........... 2 31 622210-041
16 703493-804 Washer..................................................... ........... 2 32 977480-001
DESCRIPTION QUAN.
Guard Knob..........................................................2
Washer..................................................................2
Spacer..................................................................1
Riving Knife.........................................................1
Anti-Kickback Bracket....................................... 1
Push Nut (5/16 in.)...............................................2
Upper Guard........................................................1
Bolt (5/16-18 X 1-3/4 in. Rd. Hd.)......................... 1
Bolt (5/16-18 X 5/8 in. Rd. Hd.)............................ 1
Square Nut.......................................................... 1
Guard Clamp Screw........................................... 1
Dust Guide.......................................................... 1
Hold Down Guard............................................... 1
Upper Guard Retainer Assembly...................... 1
Screw (1/4-20 x 9/16 in. Flat Hd. T. F.)............... 4
Bolt (1/4-20 X 5/8 in. Rd. Hd.).............................1
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
