CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220381
The model number will be found on a plate attached to the base. Always mention the model number
in all correspondence regarding your RADIAL ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE B
KEY PART
NO. NUMBER DESCRIPTION QUAN.
1 ** STD541031 * Hex Nut (5/16-18)....................................................................... ...............4
2 ** STD551131 * Lock Washer (5/16).................................................................... ...............4
3 624088-002 Washer....................................................................................... ...............8
4 976698-001 Table Support............................................................................ ...............2
5 931275-028 Washer....................................................................................... ...............4
6 ** STD551131 * Lock Washer (5/16).................................................................... ...............4
7 “ STD541031 * Hex Nut (5/16-18)....................................................................... ...............4
8 976339-001 Clamp Bracket.......................................................................... ...............2
9 976340-001 Clamp Screw............................................................................. ...............2
10 624282-002 Square Nut................................................................................ ...............2
11 977249-001 Cup Washer (Table Clamp)..................................................... ...............2
12 ” STD523106 * Bolt (5/16-18 X 5/8 in. Hex Hd.)................................................. ...............4
13 976834-001 * Bolt (5/16-18 X 3/4 in. Sq. Hd.).................................................. ...............4
14 976335-001 Front Table................................................................................ ...............1
15 976334-001 Fence......................................................................................... ...............1
16 976333-001 Spacer Table............................................................................. ...............1
17 976332-001 Rear Table................................................................................. ...............1
18 931744-059 Washer...................................................................................... ...............5
19 607737-004 * Screw (1/4-20 x 1-3/4 in. Pan Hd.)............................................ ...............1
20 989594-003 * Setscrew (1/4-20 x 1-1/4 in.)...................................................... ...............1
21 ** STD512510 * Screw (1/4-20 x 1 in. Pan Hd.).................................................. ...............4
22 976791-001 Tee Nut...................................................................................... ...............1
23 976792-001 “U” Clip Nut............................................................................... ...............1
24 703473-089 Lock Washer............................................................................. ...............4
25 ** STD541025 * Hex Nut (1/4-20)......................................................................... ...............4
26 977481-001 Handle Cap................................................................................ ...............1
27 977491-001 Screw (M8 X 1-1/4 in. Pan Hd. Slotted)................................... ...............1
28 977229-001 Handle....................................................................................... ...............1
29 940021-008 * Screw (10-24 x 5/8 in. Soc. Hd.)............................................................... 1
30 621032-002 Star Washer.............................................................................. ............... 1
31 977227-001 Handwheel Assembly (Includes Key Nos. 26, 27, 28).......... ............... 1
32 976361-000
972000-705
Leg Stand Assembly................................................................
Owner’s Manual (Not Shown)
............... 1
Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
63 CRnrnMmr RADIAL SAW 315.220381
