------------------- CRAFTSMAN RADIAL ARM SAW - MC )DEL NO. 315.2 20381 ---------------------------------------------------------
The model number will be found on a plate attached to the base. Always mention the model number in all coirespondence regarding your RADIAL
ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART KEY PART
NO. NUMBER DESCRIPTION QUAN. NO. NUMBER DESCRIPTION QUAN.
1 976830-001 Lower Arm Cover............................................ . 1 28 976354-001 Miter Indicator................................................... 1
£ ” STD611006 * Screw (10-16 X 5/8 in. Pan Hd.)...................... .4 29 980532-001 Miter Scale Label.............................................. 1
980667-001 Cord Label (Control Cut Power Cord).......... .1 30 980447-001 Strain Relief....................................................... 2
C
976793-001 Control Cut Power Cord................................. .1 31 641700-008 * Screw (10-32 X 5/8 in. Pan Hd.)........................ 4
6 980669-001 Cord Label (Motor Power Cord).................... .1 32 976327-002 Arm Cover......................................................... 1
7 976786-001 Motor Power Cord........................................... .1 33 980550-001 Guard Label....................................................... 1
8 976834-002 * Bolt (3/8-16 X 2-1/4 in. Sq. Hd.)....................... .2 34 976393-001 Guard Assembly............................................... 1
9 “ STD511103 * Screw (10-32 X 3/8 in. Pan Hd.)...................... .1 35 980697-001 Guard Warning Label....................................... 1
10 989001-002 Cable Clamp.................................................... ..2 36 981241-001 Warning Label................................................... 1
11 ** STD600803 * Screw (8-32 x 3/8 in. Pan Hd. T. C.)................ .4 37 980542-001 Miter Lock Label............................................... 1
12 976342-001 Arm Bearing.................................................... .2 38 980544-001 Warning Label (Right Side).............................. 1
13 703776-098 Washer............................................................. .4 39 976331-001 Arm Cap............................................................. 1
14 ** STD541437 * Lock Nut (3/8-16).............................................. .2 40 980546-001 Warning Label (Left Side)................................ 1
15 967917-001 Cord Clamp...................................................... .2 41 976863-001 Switch Key......................................................... 1
16 990908-009 * Screw (6-19 x 5/8 in. Pan Hd.).......................... .4 42 ** STD510803 * Screw (8-32 X 3/8 in. Pan Hd.).......................... 1
17 976384-001 Rear Cover....................................................... .1
43 976862-002 Switch................................................................ 1
18 ** STD511103 * Screw (10-32 x 3/8 in. Pan Hd.)....................... .3 44 ** STD551131 Lock Washer..................................................... 1
19 621380-007 * Screw (3ffl-16 x 2-1/8 in. Hex Hd. Locicng) .2 45 977471-001 Tag...................................................................... 1
20 976328-001 Arm Cover Pad................................................ .1
46 969220-005 * Screw (5/16-18 X 3/8 in. Socket Hd.)................. 1
21 624282-003 Square Nut (3/8-16)......................................... .2 47 976368-001 Cord Clamp....................................................... 1
24 980534-001 Control Cut Warning....................................... .1
48 ” STD512505 * Screw (1/4-20 X 1/2 in. Pan Hd.)........................ 1
25 976829-001 Upper Arm Cover............................................ . 1
49 642409-002 * Screw (10-16 X 41/64 in. Pan Hd.)..................... 4
26 ** STD511105 * Screw (10-32 X 1/2 in. Pan Hd.)....................... .2
50 976369-001 Cable Bracket.................................................... 1
27 976344-001 Miter Cap......................................................... .1
* Standard Hardware Item -- May Be Purchased Locally
s____
** Available From Div. 98 — Source 980.00
