CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220381
The model number will be found on a plate attached to the base. Always mention the model number
in all correspondence regarding your RADIAL ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE F
KEY PART
NO. NUMBER DESCRIPTION QUAN.
1 980548-001 Carriage Lock Label ................................................................. .........................1
2 976358-001 Carriage Lock Knob...................................................... .........................1
3 ** STD511105 * Screw (10-32 X 1/2 in. Pan Hd.)...................................... .........................4
4 976287-001 Carriage Cover (LH)...................................................... .............................. 1
5 976348-001 Rip Scale Indicator........................................................ ......................... 2
6 " STD510606 * Screw (6-32 X 5/8 in. Pan Hd.)........................................ ......................... 4
7 976352-001 Speed Nut....................................................................... .........................2
8 976409-001 Swivel Latch Spring...................................................... .............................. 1
9 976286-002 Carriage ......................................................................................... .............................. 1
10 976831-001 Thrust Washer ............................................................................ .............................. 8
11 976285-001 Carriage Bearing ........................................................................ .............................. 4
12 976337-001 Washer ........................................................................................... .............................. 4
13 976349-001 Eccentric Screw ......................................................................... .............................. 2
14 976350-001 Rip Lock Shoe ............................................................................ .............................. 1
15 976353-001 Bumper .......................................................................................... .............................. 2
16 976278-001 Yoke Clamp Stud Assembly ................................................. .............................. 1
17 999982-001 Washer ........................................................................................... ............................... 2
18 ** STD541462 * Lock Nut (5/8-11) ......................................................................... ...............................
1
19 976385-001 Sleeve Bearing ............................................................................ ............................... 2
20 620074-001 * Bolt (5/16-18 X 1-1/2 in. Hex Hd.) ........................................... ............................... 2
21 615570-020 * Bolt (5/16-18 x3/4 in. Hex Hd.)....................................... ..........................2
22 " STD551231 * Lock Washer (5/16)......................................................... ..........................2
23 624088-002 Washer ........................................................................................... ............................... 2
24 976345-001 Spring Bracket ............................................................................ ............................... 1
25 976771-001 Index Spring ................................................................................ ................................ 1
26 976346-001 Yoke Pivot Latch ........................................................................ ............................... 1
27 976288-001 Carriage Cover (RH) ................................................................. ....................... ;......
1
28 976347-002 Index Pin Housing ..................................................................... ............................... 1
29 624282-002 * Square Nut (5/16-18) .................................................................. ............................... 2
30 ** STD541031 * Hex Nut (5/16-18) ......................................................................... ...............................
4
31 980538-001 Yoke Lock Label ........................................................................ ............................... 1
32 976472-001 Yoke Lock Handle (Includes Key No. 31) ........................ ............................... 1
33 980524-001 Switch Label................................................................... ..........................1
34 980526-001 Warning Label................................................................ ..........................1
Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
