CRAFTSMAN RADIAL ARM SAW - MODEL NO. 315.220381
The model number will be found on a plate attached to the base. Always mention the model number
in all correspondence regarding your RADIAL ARM SAW or when ordering repair parts.
PARTS LIST FOR FIGURE D
KEY PART
NO. NUMBER DESCRIPTION QUAN.
1 981356-001 Data Plate...........................................................................
2 976308-001 Base Assembly.................................................................. .................... 1
3 976386-001 * Screw (5/16-18 X 3/4 in. Hex Washer Hd.)........................ .................... 2
4 976296-001 Elevation Nut...................................................................... .................... 1
5 976294-001 Column Assembly............................................................. .................... 1
6 976293-001 Retaining Ring................................................................... .................... 1
7 976292-001 Arm Latch...........................................................................
8 " STD503705 * Setscrew (3/8-16 x 1/2 in. Soc. Hd.)................................... .................... 3
9 ** STD541031 * Hex Nut (5/16-18)................................................................ .................. 17
10 977492-001 * Locking Cap Screw (1/4-20 x 5/8 in.)................................. .................... 2
11 976289-002 Support (LH)....................................................................... .................... 1
12 976295-001 Column Tube GIB.............................................................. .................... 2
13 976833-001 Elevating Shaft Assembly................................................. .................... 1
14 976290-002 Support (RH)....................................................................... .................... 1
15 615570-022 * Bolt (5/16-18x2 in. HexHd.).................................................. .................. 12
16 615570-021 * Bolt(5/16-18x2in. HexHd.).................................................... .................... 2
17 ** STD523712 * Bolt (3/8-16 x 1-1/4 in. Hex Hd.)......................................... .................... 4
18 617264-001 Washer................................................................................ .................... 8
19 615570-020 * Bolt (5/16-18 X 3/4 in. Hex Hd.)........................................... .................... 2
20 ** STD551137 * Lock Washer (3/8)............................................................... .................... 4
21 615570-007 * Bolt (5/16-18 X 1-1/8 in. Hex Hd.)........................................ .................... 1
22 " STD541037 * Hex Nut (3/8-16).................................................................... .................... 4
23 976301-001 Elevating Crank Shaft......................................................... .................... 1
24 “ STD581062 Retaining Ring.................................................................... .................... 1
25 976302-001 Bushing............................................................................... .................... 1
26 623111-006 Retaining Ring.................................................................... .................... 1
27 622141-002 Washer................................................................................. .................... 2
28 976300-001 Elevating Shaft Bearing..................................................... .................... 1
29 706239-932 Washer................................................................................. .................... 2
30 976299-001 Bevel Pinion Gear............................................................... .................... 1
31 623111-001 Retaining Ring.................................................................... .................... 1
32 “ STD571450 * Lock Nut (1/2-13).................................................................. .................... 1
33 976298-001 Bevel Gear........................................................................... .................... 1
34 976297-001 Bearing................................................................................. .................... 2
* Standard Hardware Item — May Be Purchased Locally
** Available From Div. 98 — Source 980.00
4
67 CRRFTSMflir RADIAL SAW 315.220381
