Connecting a DBS (Direct
Broadcast Satellite) Receiver
1
Connect the cable from the satellite antenna to
the DBS receiver.
2
Attach the coaxial cable from the incoming
cable connection or antenna to VHF/UHF on
the projection TV.
3
Using AUDIO and S VIDEO cables, connect
AUDIO and S VIDEO OUT on the DBS
receiver to AUDIO and S VIDEO IN on the
projection TV (White-AUDIO Left, Red-
AUDIO Right).
Note:
• To view input from the DBS, select the video input
which the DBS receiver is connected to by pressing
TV/VIDEO on the remote control.
Disconnect all power sources before making any connections.
(Rear of projection TV)
Cable/ Satellite antenna
3
0)
3
(Q
0)
3
Q.
O
o
3
3
0
3'
(Q
3
1 <6* o 3 11
o'
