Specifications
Audio Power Specifications
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION
With 8-ohm load, both channels driven,
from 20 - 20,000 Hz, rated 120 watts per
channel minimum RMS power, with no
more than 0.04 % total harmonic
distortion from 250 milliwatts to rated
output.
Surround mode
(8 ohms)
FRONT (at 1 kHz) 80 W/ch
CENTER* (at 1 kHz) 80 W
REAR (at 1 kHz) 30 W/ch
■ (only in the DOLBY SUR, THEATER and LIVE modes)
Other Specifications
Amplifier section (Front)
Continuous RMS power output (8 ohms, at 20 Hz-20 kHz)
130 W-r 130 W
Dynamic power
output (in the
stereo mode)
8 ohms,
at 1 kHz IHF
185 W+ 185 W
4 ohms,
at 1 kHz IHF
235 W + 235 W
Frequency
response
PHONO RIAA equalization curve ±0.5
dB
CD, DAT,
TAPE 1,2
VIDEO 1,2,3
10 Hz-20kHz:“dB
Damping factor
(8 ohms, at 1kHz)
50
Input sensitivity/
impedance
PHONO MM 2.5 mV, 50 kilohms
CD,DAT,
TAPE 1,2
VIDEO 1,2,3
250 mV
50 kilohms
S/N PHONO MM 83 dB
76 dB" (A,2.5mV)
CD, DAT
TAPE 1,2
VIDEO 1,2,3
85 dB
78 dB” (A,150mV)
Output sensitivity/
impedance
DAT OUT,
TAPE OUT 1,2
VIDEO 1
250 mV
10 kilohms
HEADPHONES Accepts headphones of high
and low impedance
MUTING -20dB
DBFB -rio dB at 70Hz
** 78IHF
Digital signal processor section
Modulation (A/D conversion) High Density Linear Converter
Demonstration (D/A conversion) High Density Linear Converter
(Pulse D/A Converter)
Sampling frequency 48 kHz
Equalizer Band 3-band, Bass/Treble/Mid
Turnover
frequency
Bass: 125 Hz- 1 kHz
Treble: 1 kHz - 8 kHz
Center
frequency
Mid: 54 Hz-8 kHz
Level ±10 dB, 1 dB step
Slope (Q) 3-step selectable. Wide, Mid,
Narrow
Surround ROOM SIZE 16-step adjustable
WALL 16-step adjustable
SEAT
POSITION F/R
16-step adjustable
SEAT
POSITION L/R
16-step adjustable
EFFECT
LEVEL
20-step adjustable
REVERB TIME 16-step adjustable
DELAY TIME" 15.0 ms-30.0 ms, 0.1 ms step
REAR LEVEL -1-10------- 50 dB, 1 dB step
CENTER
LEVEL***
±10 —-50dB, 1 dBstep
INPUT
BALANCE
Automatic
'* (only in the DOLBY SUR mode)
— (only in the DOLBY SUR, THEATER and LIVE modes)
40
