[n POWER switch
[U EDIT VIDEO/AUDIO buttons (See pages 25, 26
¡A1 Remote sensor
[4] Display
[5] CURSOR MODE indicators
(See pages 16, 21,30, 31,33, 36.)
[s] Cursor mode operation buttons
(See pages 16, 21,30. 31. 33, 36.)
Iz] CURSOR MODE button
(See pages 16, 21, 30, 31, 33, 36.)
[s] DBFB button and indicator (See page 14 )
[U MASTER VOLUME control (See page 14 )
|T0| SPEAKERS selector (See page 14.)
lH] HEADPHONES jack
¡H] MUTING button and indicator (See page 14 )
[H VIDEO 3/INPUT jacks
iH]
BALANCE control (See page 14.)
[m DISPLAY GRAPHIC button (See page 36.)
d] DISPLAY INDEX button (See pages 18, 22.)
[
it
]
index
SELECT/TUNING -/+ buttons
(See pages 18, 22.)
d PRESET TUNING -/+ buttons (See page 22.
[d TUNING LEVEL button (See page 18.)
d MEMORY button (See pages 16, 19, 21.)
[2T] DIRECT TUNING button (See page 17.)
id FM MODE button (See page 17.)
[
23
] FM/AM button (See pages 17, 18.)
[24]
SOUND FIELD LINK button (See page 37.)
d SOUND FIELD ON/OFF button (See pages 30, 31.)
d SOUND FIELD USER/PRESET button
(See pages 33, 36, 37.)
d DOLBY PRO LOGIC MODE button
(See pages 29, 30.)
d EQUALIZER FLAT button (See page 36.)
d EQUALIZER SLOPE button (See page 36 )
d EQUALIZER BAND button (See page 36.)
d TAPE 2 MONITOR button and indicator
(See page 24.)
d SHIFT button (See pages 19, 20, 21.)
d FUNCTION/SOUND FIELD/PRESET TUNING buttons
(See page 9.)
d MODE SELECT button (See page 9.)
