Tomei Powered OVERSIZED FUEL PUMP (For FD3S) - Manual (Page 8)

Removing the gasoline whilst arranging the fuel piping.
① Remove the fuel pumps coupler.
② Remove the fuel filler cap to release the internal pressure from the tank.
③ When the engine dies, crank the engine 3~4 times to get the fuel back into the system.
④ Turn the ignition switch OFF, remove the negative terminal of the battery.
INSTALLATION
Prior to beginning the installation process, please remove all fuel from the fuel tank.
Making sure it is not exposed to the open air.
Remove the fuel pump from the fuel tank.
Carefully secure the float in the tank, making sure not to
damage it.
Remove the bolt that secures the
bracket to the Fuel Pump.
Disconnect the Blue
coupler from the Fuel
Pump Harness
8
