Tomei Powered TURBO OUTLET (DOWN PIPES) - Manual (Page 6)

1. STUD BOLT INSTALLATION
Install the stud with the double nut fitted onto the TOMEI outlet pipe.
① Fit the double nut on the long treaded side
of the stud bolt.
② Install the stud bolt to the TOMEI outlet pipe.
③ Tighten the nut with a torque wrench.
Torque M10 24.5～29.4Ｎ・ｍ （2.5～3.0ｋｇｍ）
④ Remove the double nut.
CAUTION * Use the double nut to mount it.
Be careful NOT to move the stud bolt when * Note the bolt length direction when
removing the nuts. installing.
If the bolt moves, you'll have to repeat the * Apply the supplied bolt smooth paste
whole process. to prevent seizure.
DOUBLE NUT SIDE
TURBO SIDE
LONG SHORT
M10 STUD BOLT
6
