3
z Vibrations are likely to damage the centrifuge, contact our service center if abnormality observed.
1. Specifications
Maximum speed 14000rpm(200-14000rpm), increment: 10rpm
Maximum RCF 18620×g, increment: 10×g
Maximum capacity 2ml×24, 0.5ml×36, 4-PCR8 serial tubes, AC24P
Timer 30seconds -99minutes-HOLD, continuous operation
Driving Motor Brushless DC motor
Safety devices
Dual door interlock, Over-speed detector, Over-temperature detector, Automatic
internal diagnosis
Power
requirements
Single-phase, 220V-240V, 50Hz/60Hz, 5A.
110V-120V, 50Hz/60Hz, 5A
Dimensions（mm） （L）280×（W）364×（H）266
Weight 12kg
Additional features Speed/RCF switch, Pulse operation, Processing display, Voice reminder
2. Declaration of Conformity
Construction in accordance with the following safety standards:
EN 61010-1
EN 61010-2-10
Construction in accordance with the following EMC standards:
EN 61326-1/ FCC Part 15 Subpart B/ IECS 001
Associated EU guidelines:
EMC-guidelines: 2004/108/EC
Centrifuge guidelines: 2006/95/EC
This ISM device complies with Canadian ICES-001.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
