Page 45
1-19
Cisco IP/TV 3400 Series Servers User Guide
OL-4467-01
Chapter 1 Introducing IP/TV Servers
Cisco IP/TV Broadcast Servers
LED Indicators
describes the Cisco IP/TV 3427 Broadcast Server front panel LEDs
and their functions.
Table 1-10
Cisco IP/TV 3427 Broadcast Server Front Panel Control Buttons
Item
Description
2
Power control button
Turns on IP/TV Server. To power down IP/TV Server, you might need
to press the power button for a few seconds.
3
Reset button
Reboots IP/TV Server. You might need to use a pen or the end of a
straightened paper clip to press the button.
Note
This is a hardware reset button and does not restore the device
to the factory default software settings.
9
CD eject button
Releases a CD from the drive. The CD-ROM drive is used for
software upgrades and disaster recovery.
Table 1-11
Cisco IP/TV 3427 Broadcast Server Front Panel LEDs
LED
Color
State
Description
1
Power on
Green
On
Indicates that power is flowing to IP/TV
Server.
Flashing
Indicates that IP/TV Server is in
standby mode.
4
SCSI or IDE bus
activity
Green
On
Indicates that there is activity on the SCSI or
IDE bus.
5
System identification
Blue
Off
This LED is not used in IP/TV Server.
6
Information
Amber
On
Indicates that the information log contains
information about certain conditions in
IP/TV Server that might affect performance.
7
System error
Amber
On
Indicates that a system error has occurred. An
LED on the diagnostic LED panel will also be
on to further isolate the error.
8
CD-ROM drive activity
Green
On
Indicates that the CD-ROM drive is in use.
