1-9
Cisco IP/TV 3400 Series Servers User Guide
OL-4467-01
Chapter 1 Introducing IP/TV Servers
Cisco IP/TV Broadcast Servers
Ethernet Port
The Cisco IP/TV 3425 and 3425A Broadcast Servers come with one integrated
dual-port Ethernet controller. This controller provides an interface for connecting
to 10-Mbps or 100-Mbps networks and provides full-duplex (FDX) capability,
which enables simultaneous transmission and reception of data on the Ethernet
local-area network (LAN).
To access the Ethernet port, connect a Category 3, 4, or 5 unshielded twisted-pair
(UTP) cable to the RJ-45 connector on the back of the device.
Serial Port
The Cisco IP/TV 3425 and 3425A Broadcast Servers have one standard serial
port.
Audio and Video Ports and Connectors
The Cisco IP/TV 3425 and 3425A Broadcast Servers have an Optibase
MovieMaker video capture card installed in PCI slot 0.
Table 1-5 describes the audio and video connectors on the Cisco IP/TV 3425 and
3425A Broadcast Servers. (See also Figure 1-4 .)
Note Only one video input can be active at a time. You cannot use a composite video
source and an S-video source simultaneously.
Table 1-5 Cisco IP/TV 3425 and 3452A Broadcast Servers—Audio and Video
Connectors
Connector Description
S-video Input from S-video
1
source (mini-DIN)
1. S-video = Super-video
Comp Input from composite video source (BNC)
V Out Output of composite video (monitors video output)
A Out Audio output (monitors audio output)
A In Input from audio source (mini-jack)
