Removal and Replacement Procedures
Compaq ProLiant ML350 Generation 3 Server Maintenance and Service Guide 2-41
COMPAQ CONFIDENTIAL Codename: Steel Dragon 2.4 Part Number: 278704-002 Last Saved On: 12/18/02 9:43 AM
Feet (Tower Model Only)
To remove the four feet from the chassis, one at a time:
1. Complete the preparation procedures. Refer to “Preparation Procedures” earlier in this
chapter.
2. Place the server upside down.
3. Remove the Torx T-15 screw that secures each foot to the chassis (1).
4. Lift up the other end of each foot (2) and pull it off the base of the chassis (3).
1
2
3
Figure 2-38: Removing the feet from the chassis
To replace the feet, reverse steps 2 through 4.
