Dell KVM 2321DS User Manual
Page 41

Installation
25
USB connection, attach the SIP’s plug to the USB port on the first
server you will be connecting to this Remote Console Switch unit
(Figure 2-11).
3 To the RJ-45 connector on the SIP, attach one end of the CAT 5 cabling
that will run from your SIP to the Remote Console Switch unit
(Figure 2-11).
4 Connect the other end of the CAT 5 cable to the desired ARI port on
the back of your Remote Console Switch unit.
5 Repeat steps 2-4 for all servers you wish to attach.
NOTE:
Power down the Remote Console Switch unit before servicing. Always
disconnect the power cord from the wall outlet.
NOTE:
In addition to Dell SIPs, the Remote Console Switch may also be connected
to devices using IQ modules, including Sun and Serial IQ modules.
