36 Controlling Your System at the Analog Ports
Figure 3-1. Example of a Main Dialog Box
NOTE: You can also press the , , or keys twice within one
second to launch the OSCAR interface. You can use this key sequence in any
place you see throughout this chapter.
Viewing the Status of Your Switch
The status of the devices in your system is indicated in the right columns of
the Main dialog box. Table 3-1 describes the status symbols.
Table 3-1. OSCAR Interface Status Symbols
Symbol Description
SIP is online.
SIP is offline or is not operating properly.
Connected switch is online.
Connected switch is offline or is not operating properly.
SIP is unavailable.
(green letter) Indicates which user channel is currently
connected to a SIP.
