Replacing the center control cover – Dell Inspiron 1320 (Mid 2009) User Manual
Page 28
Replacing the Center Control Cover
1.
Align the tabs on the center control cover and snap the cover in place.
2.
Turn over the computer and replace the screw that secures the center control cover to the computer base.
3.
Replace the battery (see
Replacing the Battery
).
Back to Contents Page
1
center control cover
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
