Coin-Cell Battery
Dell™ Inspiron™ 1320 Service Manual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
Removing the Coin-Cell Battery
1. Follow the procedures in Before You Begin .
2. Remove the battery (see Removing the Battery ).
3. Remove the module cover (see Removing the Module Cover ).
4. Use a plastic scribe and gently pry the coin-cell battery.
Replacing the Coin-Cell Battery
1. Place the coin-cell battery with the positive (+) side facing upwards.
2. Slide the coin-cell battery into the slot and gently press until it snaps into place.
3. Replace the module cover (see Replacing the Module Cover ).
4. Replace the battery (see Replacing the Battery ).
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
CAUTION: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell™
is not covered by your warranty.
CAUTION: To help prevent damage to the system board, remove the main battery (see Removing the Battery ) before working inside the
computer.
1 coin-cell battery 2 plastic scribe
