CY62137FV30 MoBL

®

Document Number: 001-07141 Rev. *F

Page 6 of 12

Switching Waveforms

Figure 5. Read Cycle 1: Address Transition Controlled

[17, 18]

Figure 6. Read Cycle 2: OE Controlled

[18, 19]

PREVIOUS DATA VALID

DATA VALID

t

RC

t

AA

t

OHA

ADDRESS

DATA OUT

50%

50%

DATA VALID

t

RC

t

ACE

t

LZBE

t

LZCE

t

PU

HIGH IMPEDANCE

I

CC

t

HZOE

t

HZCE

t

PD

t

HZBE

t

LZOE

t

DBE

t

DOE

IMPEDANCE

HIGH

I

SB

DATA OUT

OE

CE

V

CC

SUPPLY

CURRENT

BHE/BLE

ADDRESS

Notes

17. The device is continuously selected. OE, CE = V

IL

, BHE and/or BLE = V

IL

.

18. WE is HIGH for read cycle.
19. Address valid before or similar to CE and BHE, BLE transition LOW.
