Removing and Installing Parts
119
NOTICE:
Do not route card cables over or behind the cards. Cables routed over the
cards can prevent the computer cover from closing properly or cause damage to
the equipment.
NOTICE:
To connect a network cable, first plug the cable into the network device
and then plug it into the computer.
11 Replace the computer cover, reconnect the computer and devices to
electrical outlets, and then turn them on.
12 If you installed a sound card:
a Enter system setup (see "System Setup" on page 170), go to Onboard
Devices and select Integrated Audio, and then change the setting to Off.
b Connect external audio devices to the sound card’s connectors. Do
not connect external audio devices to the microphone,
speaker/headphone, or line-in connectors on the back panel. See "Back
Panel Connectors" on page 18.
1 card retention release lever 2 card retention bracket
3 PCI card 4 PCI card slot
2
1
3
4
