5. Remove the inverter board (see Removing the Inverter Board ).
6. Remove the display panel assembly.
7. Remove the eight screws (four on either side)securing the display bracket.
Replacing the Display Panel
1. Attach the display brackets to the display panel by replacing the eight screws (four on either side).
2. Replace the inverter board (see Replacing the Inverter Board ).
3. Align the display panel assembly and the inverter board with the display cover.
4. Replace the four screws securing the display panel assembly to the display cover.
5. Replace the two screws securing the inverter board to the display cover.
6. Replace the display bezel (see Replacing the Display Bezel ).
7. Follow the instructions in Replacing the Display Assembly .
Display Panel Cable
Removing the Display Panel Cable
1. Follow the instructions in Removing the Display Assembly .
1 display panel screw (4) 2 inverter board screw (2)
3 inverter board 4 display panel
1 screw (8 total; 4 on each side) 2 display panel bracket (1 left, 1 right)
NOTE: The Display Panel cables and connectors may differ depending on the Display Panel you ordered.
