2. Remove the computer cover (see Removing the Computer Cover ).
3. Remove the drive panel (see Removing the Drive Panel ).
4. Disconnect the power and data cables from the back of the Media Card Reader.
5. Slide the drive release latch towards the base of the computer to release the shoulder screw, and then slide the media card reader out of the drive bay.
6. Replace the drive panel (see Replacing the Drive Panel ).
7. Replace the computer cover (see Replacing the Computer Cover ).
8. Connect the computer and devices to electrical outlets, and turn them on.
Installing a Media Card Reader
1. Follow the procedures in Before You Begin .
2. Remove the computer cover (see Removing the Computer Cover ).
1 media card reader power cable 2 system board connector
1 drive release latch 2 media card reader
NOTICE: To connect a network cable, first plug the cable into the network port or device and then plug it into the computer.
