Adaptec U320 SCSI RAID 0 or 1 Specifications
Adaptec™ U320 SCSI RAID 0 or 1 User's Guide
General
Physical
Electrical
Environmental
Reliability
General
Specification Description
Manufacturer Adaptec, Inc.
Model Number ASC-39320
Card Size 6.421 inches x 3.6 inches
Controller Interface Logic Adaptec AIC-7902
SCSI Controller Two Channels
Interface Revision Ultra320 SCSI
Interface Data Transfer Rate 320 MB/s per channel
Supported Device Types SCSI Hard Disk Drives
Number of Devices Supported 15 devices per channel/30 total devices suported
Host Bus Interface Protocol 133 MHz PCI-X
System Bus Tranfer Rate Up to 1,066 MB/s at 64-bit/133 MHz
Basic Input/Output System (BIOS) Yes
RAID Levels Supported RAID 0, 1
SCSI Connectors Two 68-pin Internal LVD/SE connectors,
Two 68-pin External VHDCI connectors
Physical
Specification Feature
