Dell Mellanox Family of Adapters - Manual (Page 55)

User Manual for Mellanox ConnectX®-3 10/40 Gigabit Ethernet Adapters for Dell PowerEdge Servers Rev 1.1
Mellanox Technologies 55
4.3 VMware Driver
For VMware, download and install the latest Mellanox Ethernet Driver for VMware vSphere 5.X
from the VMware support site:
http://www.vmware.com/support .
4.3.1 Installing and Running the Driver
4.3.1.1 Installing and Running the VIB Driver on ESXi-5.x
1. Log into the VMware ESXi server machine as root.
2. You can either:
a. Remove any earlier version of the driver from your VMware ESXi server machine prior to installing the new
version. Run:
b. Install the mlx4_en driver VIB package. Run:
c. Reboot ESXi server (The driver will be loaded automatically).
OR
a. Update the driver. Run:
b. Reboot ESXi server (The driver will be loaded automatically).
» To verify that the driver is loaded, run:
tx_tso_packets Number of packet that were aggregated
Table 14 - Per Ring (SW) Statistics (where is the ring I – per configuration)
Counter Description
rx_packets Total packets successfully received on ring i
rx_bytes Total bytes in successfully received packets on ring i.
tx_packets Total packets successfully transmitted on ring i.
tx_bytes Total bytes in successfully transmitted packets on ring i.
#> esxcli software vib list
#> esxcli software vib remove –n net-mlx4-en
#> esxcli software vib install –v
#> esxcli software vib update –v
#> vmkload_mod -l | grep mlx4_en
Table 13 - SW Statistics
Counter Description
