60 Installing System Components
Figure 3-2. Opening and Closing the System
Closing the System
1 Align the cover with the slots on the bottom of the chassis. See Figure 3-2.
2 Press down on the cover until the cover release tab snaps into place.
3 Place the system upright on a flat, stable surface.
4 Reattach any peripherals and connect the system to an electrical outlet.
5 Turn on the system and attached peripherals.
1 release tab
1
