About Your System
15
Guidelines for Connecting External Devices
• Turn off power to the system and external devices before attaching a new
external device. Turn on any external devices before turning on the system
(unless the documentation for the device specifies otherwise).
• Ensure that the appropriate driver for the attached device has been
installed on the system.
• If necessary to enable ports on your system, use the System Setup program.
See "Using the System Setup Program and UEFI Boot Manager" on
4
Power supply
305 W power supply.
5
Cable clasp
Secures the power cable.
6
USB connectors (4)
Connect USB devices to the system. The
ports are USB 2.0-compliant.
7
eSATA connector
Connects additional storage devices.
8
Serial connector
Connects a serial device to the system.
9
Video connector
Connects a VGA display to the system.
10
Ethernet connector
Integrated 10/100/1000 NIC connector.
11
PCIe expansion card
slots (4)
Connects up to four PCI Express
expansion cards.
Item
Indicator, Button, or
Connector
Icon
Description
