Dell PowerEdge R510 User Manual
Page 24

24
About Your System
9
System status
indicator
Lights blue during normal
system operation.
Both the systems management software
and the identification buttons located
on the front and back of the system can
cause the indicator to flash blue to
identify a particular system.
Lights amber when the system needs
attention due to a problem.
10
System identification
button
Turns the system ID modes on and off.
The identification buttons on the front
and back panels can be used to locate a
particular system within a rack. When
one of these buttons is pushed, the
LCD panel on the front and the system
status indicator on the chassis back
panel light blue until one of the
buttons is pushed again.
11
Power supply 2 (PS2)
750 W/1100 W redundant power
supply
12
Power supply 1 (PS1)
750 W/1100 W redundant power
supply
NOTE:
Systems with cabled hard drives
support a non-redundant power supply
unit of 480 W.
Item
Indicator, Button, or
Connector
Icon
Description
book.book Page 24 Friday, November 20, 2009 2:56 PM
