68
Video Record
Click VideRecord tab, a drop-down menu items are displayed and each menu
items are explained below.
Procedure
NOTE: Before you start recording, you have to enter the settings.
1 Click Video Record > Settings to open the settings page as shown in the
screenshot below.
2 Enter the Video Length in seconds.
3 Browse and enter the location where you want the video to be saved.
4 Enable the option Normalized video resolution to 1024X768.
5 Click OK to save the entries and return to the Console Redirection screen.
6 Click Cancel if you don't wish to save the entries.
7 In the Console Redirection window, click Video Record > Start Record.
8 Record the process.
9 To stop the recording, click Video Record > Stop Record.
Table 1-35. Video Record Description
Item Description
Start Record This option is to start recording the screen.
Stop Record This option is used to stop the recording.
Settings To set the settings for video recording
