About Your System

2

External mini-SAS

connector A2

Connects to a compute sled’s host bus

adapter (HBA) or RAID card. When you

configure zoning for the storage sled, the

external mini-SAS connector becomes

zone group 0.

3

External mini-SAS

connector A1

Connects to a compute sled’s host bus

adapter (HBA) or RAID card. When you

configure zoning for the storage sled, the

external mini-SAS connector becomes

zone group 1.

4, 8

Sled power/status

indicator

The power/status indicator lights green

when the sled power is on and power is

applied to the SAS expander board.
The power/status indicator alternately

lights green and blinks amber when a

critical event occurs.

5, 9

Sled identification

indicator

Lights blue to identify a particular mini-

SAS connector and sled.

6

External mini-SAS

connector B2

Connects to a compute sled’s host bus

adapter (HBA) or RAID card. When you

configure zoning for the storage sled, the

external mini-SAS connector becomes

zone group 2.

7

External mini-SAS

connector B1

Connects to a compute sled’s host bus

adapter (HBA) or RAID card. When you

configure zoning for the storage sled, the

external mini-SAS connector becomes

zone group 3.

10

Sled release tab

Press to release the sled from the

enclosure.

11

Hard-drive cage release

latch

Press to release the hard-drive cage from

the sled.

Item

Indicator, Button, or
Connector

Icon

Description
