Using the Expander Flash Utility
Note: XXX represents the version number of the firmware image for flash region 2.
Note: XXX represents the version number of the manufacturing image for flash region 3.
Note: 1 represents the configuration type and expander chip properties. XXX represents version
number of the manufacturing image for flash region 9.
Table 4-5. Region 2 Expander Firmware File Names
Configuration Type
Firmware Image File Name
Region
1 Expander A/B
sas2xfwZeus_XXX.fw
2
2 Expander A/B
sas2xfwZeus_XXX.fw
2
3 Expander A/B
sas2xfwZeus_XXX.fw
2
4 Expander A/B
sas2xfwZeus_XXX.fw
2
5 Expander A/B
sas2xfwZeus_XXX.fw
2
Table 4-6. Region 3 Expander Manufacturing File Names
Configuration Type
Manufacturing Image File Name
Region
1 Expander A/B
sas2xMfgZeus_XXX.bin
3
2 Expander A/B
sas2xMfgZeus_XXX.bin
3
3 Expander A/B
sas2xMfgZeus_XXX.bin
3
4 Expander A/B
sas2xMfgZeus_XXX.bin
3
5 Expander A/B
sas2xMfgZeus_XXX.bin
3
Table 4-7. Region 9 Expander Manufacturing File Names
Configuration Type
Manufacturing Image File Name
Region
1 Expander A/B
sas2xMfgZeus_1_Region9_XXX.bin
9
2 Expander A/B
sas2xMfgZeus_2_Region9_XXX.bin
9
3 Expander A/B
sas2xMfgZeus_3_Region9_XXX.bin
9
4 Expander A/B
sas2xMfgZeus_4_Region9_XXX.bin
9
5 Expander A/B
sas2xMfgZeus_5_Region9_XXX.bin 9
