Package Diagrams
Figure 14. 44-Pin TSOP II
MAX
MIN.
DIMENSION IN MM (INCH)
11.938
(0.470)
PLANE
SEATING
PIN 1 I.D.
44
1
18.517 (0.729)
0.800 BSC
0°-5°
0.400(0.016)
0.300 (0.012)
EJECTOR PIN
R
G
O
K
E
A X
S
11.735
(0.462)
10.058
(0.396)
10.262
(0.404)
1.194
(0.047)
0.991
(0.039)
0.150
(0.0059)
0.050
(0.0020)
(0.0315)
18.313 (0.721)
10.058 (0.396)
10.262 (0.404)
0.597 (0.0235)
0.406 (0.0160)
0.210 (0.0083)
0.120 (0.0047)
BASE PLANE
0.10 (.004)
22
23
TOP VIEW BOTTOM VIEW
