ADVANCE CY14E102L, CY14E102N
Document Number: 001-45755 Rev. *A Page 13 of 21
Figure 9. AutoStore or Power Up RECALL
[26]
Figure 10. CE Controlled Software STORE/RECALL Cycle [19]
Switching Waveforms (continued)
V
CC
V
SWITCH
t
STORE
t
STORE
t
HRECALL
t
HRECALL
AutoStore
POWER-UP RECALL
Read & Write Inhibited
STORE occurs only
if a SRAM write
has happened No STORE occurs
without atleast one
SRAM write
t
VCCRISE
Note
26. Read and Write cycles are ignored during STORE, RECALL, and while VCC is below V
SWITCH
.
