About Your Computer
25
CAUTION:
The AC adapter works with electrical outlets worldwide. However,
power connectors and power strips vary among countries. Using an incompatible
cable or improperly connecting the cable to the power strip or electrical outlet
may cause fire or equipment damage.
NOTICE:
When you disconnect the AC adapter cable from the computer, grasp the
connector, not the cable itself, and pull firmly, but gently to help prevent damage to
the cable.
NOTE:
Plug the power cord and the adapter firmly in, and ensure that the
green light is on.
U S B CONNECTORS
VIDEO CONNECTOR
NETWORK CONNECTOR ( R J - 4 5 )
MODEM CONNECTOR ( R J - 1 1 )
I E E E 1 3 9 4 CONNECTOR — Connects devices supporting IEEE 1394a high-speed
transfer rates, such as some digital video cameras.
H ARD D RIVE — Stores software and data.
Connect USB devices, such as a mouse, keyboard, or printer.
Connects video devices, such as a monitor.
Connects the computer to a network. The two lights next to the
connector indicate status and activity of wired network connections.
For information on using the network adapter, see the device user
guide supplied with your computer.
Connect the telephone line to the modem connector.
For information on using the modem, see the modem
documentation available online.
