CHAPTER 3: INSTALLATION
3-10
SEH USER’S GUIDE
2. Slide the new EPIM into place, making sure that the connectors on the
rear of the EPIM align correctly and firmly with the connector inside
the SEH. Refer to Figure 3-8.
3. Install the mounting screw.
Figure 3-8. Installing an EPIM
1490_12
LNK
EPIM-T
EPIM-1
EPIM-2
SEH Book Page 10 Tuesday, March 19, 1996 4:12 PM
