OPTIONAL FEATURES
SEH USER’S GUIDE 1-5
Table 1-2 lists the board revision requirements for EPIMs used in the
SEH-24. The board revision number is located on the EPIM’s printed
circuit board directly after the part number as shown in Figure 1-2.
Figure 1-2. EPIM Board Revision Number
Table 1-2. EPIM Board Revision Requirements
EPIM EPIM BOARD REVISION
EPIM-A Not Applicable
EPIM-C 05 or greater
EPIM-T 04 or greater
EPIM-X 02 or greater
EPIM-F1 05 or greater
EPIM-F2 05 or greater
EPIM-F3 02 or greater
CABLETRON SYSTEMS INC. PN 9000474 - 04
EPIM Board Revision
EPIM-T
1490_2
